Battle Armor Implements - Tough Three-Point Hitch Tractor Attachments

Durable Three Point Hitch Attachments to Enhance the Capabilities of Your Tractors...

Our line of Battle Armor tough three-point hitch implements are crafted for a lifetime of work around the field and farm. Built from heavy-gauge, welded and fabricated steel, they’re more than ready to pull their weight around on your property.

Box Blades and Land Graders Available In Five Colors - Pick the perfect match for your tractor

Box Blades and Land Graders Available In Five Colors: Pick the perfect match for your tractor.

Battle Armor Box Blade Battle Armor Land Grader with Optional Shanks
Battle Armor Grading Blade Grading Blade and Landscape Rake both feature pin adjustable, easy-angle swivel plates Battle Armor Landscape Rake
Battle Armor Trailer Mover Battle Armor Middle Buster and Subsoiler
Battle Armor 3-Spear Hay Fork & 2-Spear Hay Fork with Trailer Mover

Battle Armor Implements Specifications

Box Blade

Width: 48"
HP Rating: 20-55
Moldboard Depth: 18
Shanks: 4 adjustable
Blades (Cutting or Scraping): 2
Weight: 389
Hitch: CAT 1 or Quick Hitch
Construction Features: 1/4˝ sides and 3/16˝ moldboard; Replaceable skids; 4˝ x 1/4˝wall square tubing main frame

Box Blade

Width: 60"
HP Rating: 25-55
Moldboard Depth: 18
Shanks: 4 adjustable
Blades (Cutting or Scraping): 2
Weight: 436
Hitch: CAT 1 or Quick Hitch
Construction Features: 1/4˝ sides and 3/16˝ moldboard; Replaceable skids; 4˝ x 1/4˝wall square tubing main frame

Box Blade

Width: 72"
HP Rating: 25-55
Moldboard Depth: 18
Shanks: 6 adjustable
Blades (Cutting or Scraping): 2
Weight: 510
Hitch: CAT 1 or Quick Hitch
Construction Features: 1/4˝ sides and 3/16˝ moldboard; Replaceable skids; 4˝ x 1/4˝wall square tubing main frame

Box Blade

Width: 84"
HP Rating: 80 Max
Moldboard Depth: 18
Shanks: 7 adjustable
Blades (Cutting or Scraping): 2
Weight: 565
Hitch: CAT 2 or Quick Hitch
Construction Features: 1/4˝ sides and 3/16˝ moldboard; Replaceable skids; 4˝ x 1/4˝wall square tubing main frame

Land Leveler/Grader

Width: 60"
HP Rating: 18-55
Moldboard Depth: 16.5
Shanks: 4 adjustable-optional
Blades (Cutting or Scraping): 2
Weight: 463
Hitch: CAT 1 or Quick Hitch
Construction Features: 1/4˝ sides; 4˝ x 1/4˝wall square tubing main frame; Replaceable skids; Fully adjustable blades

Land Leveler/Grader

Width: 72"
HP Rating: 18-55
Moldboard Depth: 16.5
Shanks: 6 adjustable-optional
Blades (Cutting or Scraping): 2
Weight: 499
Hitch: CAT 1 or Quick Hitch
Construction Features: 1/4˝ sides; 4˝ x 1/4˝wall square tubing main frame; Replaceable skids; Fully adjustable blades

Land Leveler/Grader

Width: 84"
HP Rating: 80 Max
Moldboard Depth: 16.5
Shanks: 7 adjustable-optional
Blades (Cutting or Scraping): 2
Weight: 570
Hitch: CAT 2 or Quick Hitch
Construction Features: 1/4˝ sides; 4˝ x 1/4˝wall square tubing main frame; Replaceable skids; Fully adjustable blades

3 Spear/3PT Hay Fork

Width: 26.5"
HP Rating: n/a
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): n/a
Weight: 79
Hitch: CAT 1
Construction Features: 49.5˝ Main Spear; 3˝ x 1/4˝ wall tubing frame; 2 17˝stabilizer bars; Spears rated at 2000 lbs.

2 Spear/3PT Hay Fork Trailer Mover Combo

Width: 26.5"
HP Rating: n/a
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): n/a
Weight: 107
Hitch: CAT 1
Construction Features: 3˝ x 1/4˝ wall tubing frame; 2@ 49.5˝ spears rated at 2000 lbs; Receiver hitch and 2 5/16˝ ball mount

3PT Trailer Mover

Width: 26.5"
HP Rating: n/a
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): n/a
Weight: 43
Hitch: CAT 1
Construction Features: 3˝ x 1/4˝ wall tubing frame; Receiver hitch and ball mount

Light Duty Middle Buster & Subsoiler

Width: 26.5"
HP Rating: 35hp 2wd
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): 12" blade width
Weight: 59
Hitch: CAT 1 or Quick Hitch
Construction Features: 3/4˝ x 3˝ solid stock main frame

Heavy Duty Middle Buster & Subsoiler

Width: 26.5"
HP Rating: 45hp 2wd
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): 16" blade width
Weight: 81
Hitch: CAT 1 or Quick Hitch
Construction Features: 1˝ x 4˝ solid stock main frame

Grader Blade

Width: 48"
HP Rating: 17-25
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): 1
Weight: 220
Hitch: CAT 1 or Quick Hitch
Construction Features: 7 Forward/7 Reverse blade positions; Tilt clockwise and counterclockwise; 1/4˝ moldboard, frame tubing; 1/4˝ wall; 3/8˝ pivot plates

Grader Blade

Width: 60"
HP Rating: 17-40
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): 1
Weight: 263
Hitch: CAT 1 or Quick Hitch
Construction Features: 7 Forward/7 Reverse blade positions; Tilt clockwise and counterclockwise; 1/4˝ moldboard, frame tubing; 1/4˝ wall; 3/8˝ pivot plates

Grader Blade

Width: 72"
HP Rating: 20-40
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): 1
Weight: 306
Hitch: CAT 1 or Quick Hitch
Construction Features: 7 Forward/7 Reverse blade positions; Tilt clockwise and counterclockwise; 1/4˝ moldboard, frame tubing; 1/4˝ wall; 3/8˝ pivot plates

Grader Blade

Width: 84"
HP Rating: 20-40
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): 1
Weight: 350
Hitch: CAT 1 or Quick Hitch
Construction Features: 7 Forward/7 Reverse blade positions; Tilt clockwise and counterclockwise; 1/4˝ moldboard, frame tubing; 1/4˝ wall; 3/8˝ pivot plates

Landscape Rake

Width: 48"
HP Rating: 17-25
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): n/a
Weight: 175
Hitch: CAT 1 or Quick Hitch
Construction Features: 7 Forward/7 Reverse blade positions; 1/4˝ frame tubing; 3/8˝ pivot plates; Tines individually mounted

Landscape Rake

Width: 60"
HP Rating: 17-40
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): n/a
Weight: 201
Hitch: CAT 1 or Quick Hitch
Construction Features: 7 Forward/7 Reverse blade positions; 1/4˝ frame tubing; 3/8˝ pivot plates; Tines individually mounted

Landscape Rake

Width: 72"
HP Rating: 20-40
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): n/a
Weight: 227
Hitch: CAT 1 or Quick Hitch
Construction Features: 7 Forward/7 Reverse blade positions; 1/4˝ frame tubing; 3/8˝ pivot plates; Tines individually mounted

Landscape Rake

Width: 84"
HP Rating: 20-40
Moldboard Depth: n/a
Shanks: n/a
Blades (Cutting or Scraping): n/a
Weight: 254
Hitch: CAT 1 or Quick Hitch
Construction Features: 7 Forward/7 Reverse blade positions; 1/4˝ frame tubing; 3/8˝ pivot plates; Tines individually mounted

Product Width HP Rating Moldboard
Depth
Shanks Blades
Scraping or Cutting
Weight Hitch Construction Features
Box Blade 48" 20-55 18 4 adjustable 2 389 lbs. CAT 1 or Quick Hitch 1/4" sides and 3/16" moldboard
Replaceable skids
4" x 1/4" wall square tubing main frame
60" 25-55 18 4 adjustable 2 436 lbs. CAT 1 or Quick Hitch
72" 25-55 18 6 adjustable 2 510 lbs. CAT 1 or Quick Hitch
84" 80 Max 18 7 adjustable 2 565 lbs. CAT 2 or Quick Hitch
Land Grader 60" 18-55 16.5 4 adjustable (optional) 2 463 lbs. CAT 1 or Quick Hitch 1/4" sides
4" x 1/4" wall square tubing main frame
Replaceable skids; Fully adjustable blades
72" 18-55 16.5 6 adjustable (optional) 2 499 lbs. CAT 1 or Quick Hitch
84" 80 Max 16.5 7 adjustable (optional) 2 570 lbs. CAT 2 or Quick Hitch
3 Spear/3PT Hay Fork 26.5" n/a n/a n/a n/a 79 lbs. CAT 1 49.5˝ Main Spear; 3˝ x 1/4˝ wall tubing frame
2 17˝ stabilizer bars; Spears rated at 2000 lbs.
2 Spear/3PT Hay Fork Trailer Mover Combo 26.5" n/a n/a n/a n/a 107 lbs. CAT 1 3˝ x 1/4˝ wall tubing frame; 2@ 49.5˝ spears rated at 2000 lbs.
Receiver hitch and 2 5/16˝ ball mount
3PT Trailer Mover 26.5" n/a n/a n/a n/a 43 lbs. CAT 1 3" x 1/4" wall tubing frame
Receiver hitch and ball mount
Light Duty Middle Buster & Subsoiler 26.5" 35hp 2wd n/a n/a 12" blade width 59 lbs. CAT 1 or Quick Hitch Light Duty: 3/4˝ x 3˝ solid stock main frame
Heavy Duty Middle Buster & Subsoiler 26.5" 45hp 2wd n/a n/a 16" blade width 81 lbs. CAT 1 or Quick Hitch Heavy Duty: 1˝ x 4˝ solid stock main frame
Grader Blade 48" 17-25 n/a n/a 1 220 lbs. CAT 1 or Quick Hitch 7 Forward/7 Reverse blade positions
Tilt clockwise and counterclockwise
1/4˝ moldboard, frame tubing 1/4˝ wall
3/8˝ pivot plates
60" 17-40 n/a n/a 1 263 lbs. CAT 1 or Quick Hitch
72" 20-40 n/a n/a 1 306 lbs. CAT 1 or Quick Hitch
84" 20-40 n/a n/a 1 350 lbs. CAT 1 or Quick Hitch
Landscape Rake 48" 17-25 n/a n/a n/a 175 lbs. CAT 1 or Quick Hitch 7 Forward/7 Reverse blade positions
1/4˝ frame tubing, 3/8˝ pivot plates
Tines individually mounted
60" 17-40 n/a n/a n/a 201 lbs. CAT 1 or Quick Hitch
72" 20-40 n/a n/a n/a 227 lbs. CAT 1 or Quick Hitch
84" 20-40 n/a n/a n/a 254 lbs. CAT 1 or Quick Hitch
Battle Armor Implements - 3-Point Tractor Attachments

For more information or to purchase, please contact Brandon with Battle Armor Designs at 877-769-1907
